| 称号 | Name | 单元/Unit | 2QYK-3600 |
2QYK-3300 |
2QYK-3600 |
2QYK-4000/4200 | 2QYK-5000 |
| 范例 | Type | A/B/C/D |
A/B/C/D |
A/B/C/D |
A/B/C/D |
A/B/C/D |
|
| 锯片直径 | Blade diameter |
mm |
Φ3000 | Φ3300 | Φ3600 |
Φ4000/Φ4200 |
Φ5000 |
| 最大切割深度 | Max.cutting depth |
mm |
1250 | 1400 | 1500 | 1750/1850 | 2250 |
|
服务器主机瓦数 |
Power ofmain motor |
kw | 55x2 | 55x2 | 55x2 | 65X2 | 65X2 |
|
液压油泵建筑机电功效 |
Power of pump motor |
kw |
3.5 | 3.5 | 3.5 | 4 | 4 |
| 路程机电功率 |
Power of stroke motor |
kw |
2.2 | 2.2 | 2.2 | 3 | 4 |
| 纵向换轨机电功率 |
|
kw |
0.75x2 | 0.75x2 | 0.75x2 | 1.1X2 | 1.1X2 |
|
器件效率 |
Gross power |
kw |
117.2 | 117.2 | 117.2 | 139.2 | 140.2 |
|
的样子尽寸 |
Dimensions(LxWxH) |
mm | 3200x2100x2800 | 3500x2200x3200 | 3800x2200x3100 | 420X2100X3500 | 5200X2200X4200 |
|
所需要的零部件净重 |
Gross weight |
kg | 7000-8500 | 7000-8500 | 7500-10000 | 9500-11500 | 9500-12500 |
| 切割宽度 | Cutting width of TypeA |
mm |
1360-1900 | 1360-1900 | 1360-1900 | 1950-2450 | 2000-2500 |
|
|
TypeB |
mm |
1800-2300 | 1800-2300 | 1900-2400 | 2400-2900 | 2400-2900 |
|
|
TypeC |
mm |
2200-2700 | 2200-2700 |
2300-2800 |
2800-3300 | 2800-3300 |
|
|
TypeD |
mm |
2700-3200 |
2700-3200 |
2700-3200 | 3200-3700 | 3200-3700 |
| 一米四机台 |
|
|
|
|
|
|
|
|
所需要的零部件图像 |
Gross weight |
kg |
7000 | 7500 | 7800 | / | / |
| 形态大小 | Dimensions(LxWxH) |
mm |
3200z1500z2630 |
3500x1500x2880 |
3700x1500x3050 |
/ | / |
|
切总宽 |
Cutting width |
mm |
1380-1880 | 1380-1880 | 1380-1880 | / | / |
| 四驱机型 |
|
|
|
|
|
|
|
| 纵横驱动机电功率 |
|
kw | 1.5x2 | 1.5x2 | 1.5x2 | 1.5X2 | 1.5X2 |
| 总功率 |
Gross power |
kw | 116.5 | 116.5 | 116.5 | 137 | 137 |
